Bovi, G. G., Rux, G., Caleb, O. J., Herppich, W. B., Linke, M., Rauh, C., & Mahajan, P. V. (2018).
Measurement and modelling of transpiration losses in packaged and unpackaged strawberries. Biosystems
Engineering, 174, 1–9. https://doi.org/10.1016/j.biosystemseng.2018.06.012
Graziele G. Bovi, Guido Rux, Oluwafemi J. Caleb, Werner B. Herppich,
Manfred Linke, Cornelia Rauh, Pramod V. Mahajan
Measurement and modelling of
transpiration losses in packaged and
unpacka
g
ed strawberries
Accepted manuscript (Postprint)Journal article |
Measurement and modelling of transpiration losses in packaged and
1
unpackaged strawberries
2
3
In: Biosystems Engineering 174, 1-9.
4
5
6
Cite as: Bovi, G.G., Rux, G., Caleb, O.J., Herppich, W.B., Linke, M., Rauh, C., & Mahajan,
7
P.V., (2018). Measurement and modelling of transpiration losses in packaged and unpackaged
8
strawberries. Biosystems Engineering, 174, 1-9.
9
doi: https://doi.org/10.1016/j.biosystemseng.2018.06.012
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Measurement and modelling of transpiration losses in packaged and unpackaged
27
strawberries
28
29
Graziele G. Bovia, b,*, Guido Rux a, Oluwafemi J. Caleba,c, Werner B. Herppicha, Manfred Linkea,
30
Cornelia Rauhb, Pramod V. Mahajana
31
32
a Department of Horticultural Engineering, Leibniz Institute for Agricultural Engineering and Bioeconomy
33
(ATB), Potsdam, Germany
34
b Department of Food Biotechnology and Food Process Engineering, Technical University of Berlin, Germany
35
c Division of Post-harvest and Agro-processing Technologies, Agricultural Research Council (ARC) Infruitec-
36
Nietvoorbij, Stellenbosch 7599, South Africa
37
38
*Corresponding author: Phone: +49(0)3315699628;
39
E-mail: gbovi@atb-potsdam.de (Graziele G. Bovi); pmahajan@atb-potsdam.de (Pramod V. Mahajan)
40
41
Abstract
42
Transpiration and respiration are physiological processes well-known as major sources of
43
fresh produce mass loss. Besides causing impairment of external quality, it is associated with
44
economic loss since it inevitably decreases saleable weight. To prevent postharvest mass
45
losses, by improved modified atmosphere and humidity packaging, comprehensive knowledge
46
on the mechanistic basis of both processes and their interactions is essential. The objective of
47
this study was to evaluate the contribution of these processes on mass loss of packaged and
48
unpackaged strawberries. Experiments on a single strawberry were performed at 4, 12 and
49
20°C; and 76, 86, 96 and 100% RH. Mass loss was also investigated as a function of number
50
of strawberries and package volume at 12°C. A combined model based on Arrhenius equation
51
and Fick´s first law of diffusion for an unpackaged single strawberry and a model based on
52
degree of filling was developed and validated with packaged strawberries. These models have
53
potential application towards the selection of optimal moisture control strategies for
54
strawberries.
55
56
Keywords: Modified atmosphere and humidity packaging, Water loss, Strawberry,
57
Transpiration, Degree of filling (DOF)
58
59
60
61
62
63
Nomenclature
64
DOF Degree of filling
65
MAP Modified atmosphere packaging
66
MAHP Modified atmosphere and humidity packaging
67
RH Relative humidity (%)
68
TR Transpiration rate
69
RR Respiration rate
70
VPD Water vapour pressure deficit
71
TRm Transpiration rate on mass basis (g kg-1 h-1)
72
mi Initial mass of the product (g)
73
mt Product mass (g) at a determined time (t) in hours (h)
74
Ps Saturation vapour pressure (kPa)
75
Pa Actual vapour pressure (kPa)
76
T Surrounding temperature (°C)
77
BOPP Bi-axially oriented polypropylene
78
Ki Mass transfer coefficient
79
awi Water activity of the commodity
80
aw Water activity of the storage air
81
a Model constant coefficient
82
Msub Mass loss due to substrate
83
TMLR Total mass loss rate
84
Vproduct Product´s volume (mL)
85
Vpackage Package´s volume (mL)
86
87
1. Introduction
88
Modified atmosphere packaging (MAP) systems have been extensively used to reduce
89
physiological activity of fresh produce by modifying in-package gas composition as well as to
90
reduce mass loss by maintaining high in-package air humidity (Caleb, Mahajan, Al-Said, &
91
Opara, 2013a). Most of the packaging materials used for MAP have low water vapour
92
permeability, and, therefore, the water vapour released by the product due to transpiration
93
remains trapped inside the package, often leading to undesirable condensation (Bovi, Caleb,
94
Linke, Rauh, & Mahajan, 2016). Thus, in order to lessen in-package water vapour
95
condensation it is essential to shift the system design from MAP to modified atmosphere and
96
humidity packaging (MAHP). The main challenge of MAHP is to reduce condensation while
97
still maintaining produce water loss as low as possible (Rodov, Ben-Yehoshua, Aharoni, &
98
Cohen, 2010). The design based on MAHP not only takes into account the gas composition
99
but also the in-package air humidity and moisture control strategies to maintain desirable
100
relative humidity (RH) and thus reduce condensation (Bovi & Mahajan, 2017).
101
In order to design appropriate MAHP it is essential to understand how much water is released
102
by the product. Water loss in fresh produce is commonly measured by quantifying the amount
103
or the mass of water lost per unit of time, the transpiration rate (TR). Many models based on
104
Fick´s first law of diffusion have been proposed to calculate the TR of a wide range of
105
horticulture products such as strawberry (Sousa-Gallagher et al., 2013), pomegranate arils
106
(Caleb, Mahajan, Al-Said, & Opara, 2013b), whole mushroom (Mahajan, Oliveira, &
107
Macedo, 2008), tomatoes (Xanthopoulos, Athanasiou, Lentzou, Boudouvis, & Lambrinos,
108
2014), and pears (Xanthopoulos, Templalexis, Aleiferis, & Lentzou, 2017). These models are
109
efficient and valid for single unpackaged products, but their application in a dynamic system
110
to estimate the TR of packaged products have not yet been tested.
111
Furthermore, the quantity of mass loss over a given period of time has long been accepted as
112
being the TR of fresh produce. This was based on the assumption that mass loss due to the
113
oxidative breakdown of organic reserves (substrate loss) and the effects that respiration exerts
114
on TR, by generating metabolic heat and by supplying additional water that can be lost in
115
transpiration, are negligible (Shirazi & Cameron, 1993; Xanthopoulos et al., 2017). Recent
116
studies, however, have pointed out the important role respiration plays on TR of fresh
117
produce, under water vapour saturated environments which is normally seen in packaged
118
fresh produce (Bovi, Caleb, Herppich, & Mahajan, 2018). For instance, Mahajan et al. (2016)
119
developed a model to calculate TR based on respiration rate (RR). The authors calculated this
120
effect on TR by multiplying RR with a conversion factor of 8.6 obtained from the respiratory
121
heat and adding it to model of TR calculations based on Fick´s first law of diffusion.
122
Furthermore, the authors indicated that the heat of respiration increased the surface
123
temperature of fresh mushroom above that of the surrounding air, thereby creating a water
124
vapour pressure deficit (VPD) that may further drive transpirational water losses. In addition,
125
Xanthopoulos et al. (2017) developed a model that analyses the contribution of transpiration
126
and respiration on water loss using pears as a model product. Water loss indirectly resulting
127
from respiration accounts for 39% of the total water loss as a result of water vapour pressure
128
deficit at an air temperature of 20 °C and 95% RH.
129
The critical challenge in modelling TR and, consequently, water loss in fresh produce is that
130
the parameters and/or coefficients of the model are product specific. Similarly, the appropriate
131
moisture control strategy also needs to be product specific and has to be optimized
132
considering the transpirational properties of each fruit or vegetable (Bovi, Caleb, Klaus, et al.,
133
2018). This challenge implies that the respective physiological features of each type of fresh
134
produce needs to be studied in detail and individually under each different storage condition
135
and packaging system. In this context, the aim of this work was to develop a model to predict
136
water loss from packaged fresh produce, with the potential application towards the selection
137
of optimal moisture control strategies. With this aim, a comprehensive case study was carried
138
out on the mass loss of packaged and unpackaged strawberries.
139
2. Materials and methods
140
2.1. Sample preparation
141
Freshly harvested strawberries were obtained from a commercial supplier (Obst und Gemüse
142
Großhandle, Beusselstraße, Berlin) and immediately transported to the Department of
143
Horticultural Engineering, Leibniz Institute for Agricultural Engineering and Bioeconomy,
144
Potsdam, Germany. The strawberries were carefully sorted for uniformity in size and colour,
145
and damaged, overripe and poor quality samples were discarded.
146
CO2-based respiration rates (RR) of strawberries were determined by continuously monitoring
147
rates of CO2 production by a novel closed-system respirometer previously described by Rux,
148
Caleb, Geyer, and Mahajan (2017). The respirometer consisted of acrylic glass cuvettes (8.2
149
L), each fitted with non-dispersive infrared CO2 sensor (GMP222, Vaisala GmbH, Bonn,
150
Germany). The RR was calculated as the amount of CO2 per unit mass of the fruit per unit
151
time (mg CO2 kg−1 h−1). Measurements were carried out for 6 h at 4, 12 and 20 °C.
152
2.2. Transpiration rate of single unpacked strawberries
153
The experimental setup consisted of four containers (190 l) located in walk-in cold rooms
154
with adjustable temperature. Three temperatures (4, 12 and 20 °C) at four different RH were
155
tested. The RH (%) inside each of the container was adjusted independently by using various
156
saturated salt solutions made from analytical grade reagents of sodium chloride, potassium
157
chloride, and potassium nitrate, for RH of 76, 86, and 96%, respectively, and pure distilled
158
water was used for 100%. Two trays containing saturated salt solutions were placed inside
159
each container and a wire mesh was placed above the trays to hold the petri-dishes containing
160
the individual strawberries. TR was calculated by a gravimetric approach according to:
161
𝑇𝑅𝑚= 𝑚𝑖− 𝑚𝑡
𝑡 . ( 𝑚𝑖
1000) (1)
162
where TRm is the transpiration rate on mass basis (g kg-1 h-1), mi is the initial mass of the
163
product (g); mt is product mass (g) at a determined time (t) in hours (h). A total of five
164
repetitions were carried out for each treatment and the mass loss was measured daily using an
165
electronic balance CPA10035 (Sartorius, Göttingen, Germany). The VPD for every
166
temperature and RH was calculated according to the equation presented by Matyssek and
167
Herppich (2017):
168
𝑉𝑃𝐷 = 𝑃𝑠− 𝑃𝑎 (2)
169
where Ps is the saturation vapour pressure (Eq. 3) and Pa is the actual vapour pressure (Eq. 4).
170
𝑃𝑠= [𝑒𝑥𝑝(52.57633− 6790.4985
𝑇+273.16 −5.02808ln𝑇 +273.16)] (3)
171
𝑃𝑎= 𝑃𝑠 𝑥 𝑅𝐻 (4)
172
where T is surrounding temperature (°C), RH is relative humidity (%), and Ps and Pa are given
173
in kPa.
174
These equations were further used to calculate the linear variation of TR as a function of
175
VPD. A regression analysis of the linear variation between TR and VPD, for every
176
temperature, was carried out using Microsoft Excel (Office 2010, Microsoft, 116 Germany).
177
A second set of experiments was performed at 100% RH, i.e. at water vapour saturation, at 13
178
°C in a storage chamber (190 l), based on the methodology reported by Mahajan et al. (2016).
179
A single strawberry was hung from the electronic scale using nylon. Distilled water was used
180
in the storage chamber in order to maintain saturated air humidity. Mass loss from the
181
strawberry was continuously monitored using an electronic balance connected to the data
182
logger (ALMEMO 2490, Ahlborn, Holzkirchen, Germany) and its surface temperature was
183
measured using an infrared temperature sensor AMIR 7842 (accuracy ±1 % from value or ±1
184
K) (Ahlborn, Holzkirchen, Germany).
185
2.3. Transpiration measurement of packaged strawberries
186
Two separate experiments were performed in order to evaluate total mass loss of packaged
187
strawberries. In the first experimental set-up, different number of strawberries (1, 3, 6 and 15)
188
were placed inside closed polypropylene containers (0.93 l) weighing (12.26 ± 1.73 g); (40.33
189
± 8.80 g), (78.57 ± 12.78 g) and (215.73 ± 49.01 g), respectively. A total of six repetitions
190
were carried out and the mass loss of individual strawberries was measured daily using an
191
electronic balance. This experimental data was then used to test the hypothesis that different
192
numbers of strawberries packaged in the fixed size of a package (0.93 l) behave differently
193
than a single strawberry.
194
In the second experiment, the mass loss of fixed amount of strawberries (200 ± 4 g) placed in
195
packages with different volumes was evaluated. For this investigation, three different
196
polypropylene packaging trays were used: a small (0.8 l), a medium (1.4 l), and a large (2.3 l);
197
and the proportion of strawberry per package size (strawberry volume: package volume) was
198
1:4, 1:7, and 1:12, respectively. All packages were filled with strawberries and covered with
199
bi-axially oriented polypropylene (BOPP) PropafilmTM RGP25 (25 mm thickness;
200
permeability rate to O2, 8.5x10-12 mol m-2 s-1 Pa-1 at 23 °C and 0% RH; water vapour, 5.7 ×
201
10-6 mol m-2 s-1 Pa-1 at 23 °C and 85% RH, Innovia Films, Cumbria, UK). The covering film
202
on the trays was perforated with 6, 5, and 4 micro-perforations of diameter 0.82 mm, for the
203
small, medium, and large tray, respectively. These perforations were made in order to
204
maintain the package atmosphere close to air and reduce condensation. Packages were stored
205
for 5 d at 12 °C and the mass loss of strawberries was measured gravimetrically.
206
2.4. Model development and experimental validation
207
A combined model based on Arrhenius equation and Fick´s first law of diffusion for
208
unpackaged single strawberries and a model based on degree of filling (DOF) for packaged
209
strawberries were developed (see section 3.3). Experimental data obtained at all combinations
210
of temperature, RH, and packaging systems studied were used to estimate the values of the
211
coefficients.
212
For the validation of the model based on DOF, strawberries were pre-cooled to the study
213
temperature of 12 °C for 3 h, and packed (15 strawberries of 200 ± 10 g) in polypropylene
214
trays (16 x 12 x 5 cm), in the proportion of strawberry and package of 1:4. The trays were
215
covered with BOPP and perforated with 6 micro-perforations of diameter 0.82 mm. Packages
216
were stored for 5 d at 12 °C. Headspace gas composition (O2 and CO2 concentrations) inside
217
each package was monitored daily using a CheckMate 3 gas analyser (PBI Dansensor,
218
Ringsted, Denmark). Mass loss was determined by weighing the strawberries at the beginning
219
of the experiment and after storage. Five replicates were carried out.
220
2.5. Statistical analysis
221
The models parameters were determined by fitting the data by non-linear regression analysis
222
and Solver tool in Microsoft Excel (Office 2010, Microsoft, Germany). Furthermore, the data
223
obtained were submitted to analysis of variance (ANOVA) and Tukey’s test with significance
224
set at p < 0.05 using the Statistica software (version 10.0, StatSoft Inc., Tulsa, USA).
225
3. Results and discussion
226
3.1.Transpiration rate of single unpacked strawberry
227
At the lowest RH the TR was highest (Fig.1) because the VPD, i.e. the driving force for
228
transpiration, was generally highest. Raising RH at 20°C from 76% to 96%, i.e. reducing
229
VPD by approx. 83% lowered TR by only 43% from 1.28 to 0.73 g kg-1 h-1. Similarly, with
230
increase in air temperature higher TR was recorded when RH was kept constant. For instance,
231
with the rise in temperature from 4°C to 20°C at 96% RH the TR increased more than 5 times
232
(from 0.13 to 0.73 g kg-1 h-1) although VPD increased only approx. threefold from 0.033 kPa
233
to 0.094 kPa. These results indicate how both temperature and VPD, or less accurately RH,
234
affect the transpiration. Similar results were found in Sousa-Gallagher, Mahajan, and Mezdad
235
(2013). In their study the TR for strawberries varied from 0.24 to 1.16 g kg-1 h-1 (at 5, 10 and
236
15 °C and 76, 86 and 96% RH), whereas in the present study TR varied from 0.13 to 1.28 (at
237
4, 12 and 20°C and same RH).
238
This was further highlighted by a comparison of residual transpiration rates in water vapour
239
saturated air (100 % RH), which pronouncedly increased 6.5-fold from 0.02 g kg-1 h-1 at 4 °C
240
to 0.13 g kg-1 h-1 at 20 °C (Fig. 1). This clearly indicated that there remained a driving force
241
for transpiration even when the air surrounding the strawberry was water vapour saturated.
242
The driving force for such water loss resulted from a higher fruit body temperature due to heat
243
generated by respiration, which was indeed more than five times higher at 20 °C that at 4°C,
244
from 30.26 to 153.18 mg CO2 kg-1 h-1 (Fig. 1). The linear variation of TR as a function of
245
VPD is shown in Fig. 2. At VPD = 0 kPa (i.e. 100 % RH), there was a residual transpiration
246
rate of 0.1737, 0.0675 and 0.0057 g kg-1h-1, at 20, 12 and 4 °C, respectively. This residual TR
247
resulted from heat of respiration which showed estimated fruit surface temperature of 20.12
248
°C, 12.07 °C and 4.01 °C.
249
Comparison of the variations of surface temperature of a strawberry and the temperatures of
250
the surrounding air allows visualisation of the effect of respiratory heat generation on
251
strawberry mass loss (Fig. 3). Fruit temperature was indeed higher than that of the
252
surrounding air. This fact implied that the heat of respiration of strawberry increased its
253
surface temperature. In turn, this temperature difference led to an increase in water vapour
254
pressure gradient for the mass transfer between the strawberry and its surrounding conditions
255
and a continuous decline of fruit mass. Therefore, results from this study agree with the
256
hypothesis that respiratory heat can significantly influence water losses from fresh fruit and
257
vegetables under water vapour saturated conditions (Chau & Gaffney, 1990; Kang & Lee,
258
1998). This was also validated by Mahajan et al. (2016) using a mushroom and a spherical
259
evaporation dummy apparatus (Linke, Schlüter, & Geyer, 2008), both stored under water
260
vapour saturated conditions. The mushroom continuously lost mass while that of the
261
evaporation sphere remained constant over time.
262
3.2. Transpiration rate as a function of fruit quantity and package volume
263
This study showed that increasing the number of strawberries inside a package resulted in
264
lower TR (Fig. 4a). When there was only a single strawberry in the package, the rate of mass
265
loss was 0.068 g kg-1 h-1, whereas with 15 strawberries mean mass losses were less than half
266
that rate, 0.027 g kg-1 h-1. Possible reasons for this reduction could be that: (i) with more
267
strawberries in a package the fresh produce tends to stay closer to each other thereby reducing
268
the effective surface area available for the transpiration and (ii) with more strawberries in the
269
same package volume, saturation is reached more rapidly, and thus the period for decreasing
270
the driving force for transpiration is effectively reduced.
271
It is well documented that the surface area available for water vapour diffusion plays an
272
important role on fresh produce water loss (Sastry, 1985). Similarly, when strawberries are
273
kept close together their overlaping area reduces the surface available for transpiration and,
274
therefore, water loss is reduced. Furthermore, the time needed for the package to reach water
275
vapour saturation is also important since when the saturation point is reached the TR
276
decreases considerably. Thus, the package headspace plays an indirect, but important, role in
277
water loss because the smaller the headpace, the quicker water vapour saturation is reached.
278
The observations recorded on the effects of varying container volumes on total mass loss (Fig.
279
4b), confirmed the hypothesis that package headspace played a major role on mass loss. When
280
the headpace was 0.6 l, mass loss was 0.019 g kg-1 h-1; increasing the free headspace to 2.1 l
281
(i.e. ≈ 350%) the rate of mass loss increased to 0.035 g kg-1 h-1 (185 %). Therefore, in order to
282
minimise mass loss from fresh produce it is important to minimise package headspace.
283
Overall, these results showed that package headspace played an important role in strawberry
284
mass loss and, therefore, TR measurements of single strawberries measured in large chambers
285
with unrestricted surrounding air flow conditions are not realistic to calculate water loss from
286
packaged fresh produce.
287
3.3. Mathematical models
288
3.3.1. Unpackaged strawberries
289
Transpiration of fresh produce has been well studied with several reports have been published
290
on mathematical modelling of transpiration rate as a function of extrinsic factors such as
291
temperature, RH and air velocity (Bovi et al., 2016; Mahajan et al., 2008; Sastry &
292
Buffington, 1983). One such model is described by:
293
TR = Ki(awi −aw)(1−e−a T) (6)
294
where TR is transpiration rate, Ki is a mass transfer coefficient, awi is water activity of the
295
commodity; aw is water activity of the storage air, a is a model constant coefficient and T is
296
temperature. This model was used to fit the experimental data at 76, 86, and 96 % RH. The
297
model parameters, as well as the comparison between the predicted and experimental data for
298
single unpackaged strawberry are shown in Fig. 5.
299
As this model was developed for the range 76 to 96% RH, extrapolating to 100 % RH (aw =
300
RH/100) would lead to zero TR. This error originated from the assumption that the surface
301
temperature is equal to the temperature of the surrounding air and there is no moisture loss
302
due to respiration heat. Therefore, such model needs to be revised for 100% RH and the
303
differences in temperature between the product and the surrounding air should be taken into
304
account. Furthermore, mass measurements also consisted of substrate loss due to respiration.
305
Such loss was calculated using the well accepted equation based on product respiration rate
306
(Kays, 1991; Saltveit, 2004):
307
𝑀𝑠𝑢𝑏 =𝑅𝑅 𝑥 (180
264) (7)
308
where, Msub is the mass loss due to substrate, RR is the respiration rate in mg CO2 kg-1 h-1 and
309
the ratio 180/264 indicates that when glucose is the substrate, 180 g of this sugar is lost for
310
each 264 g of CO2 produced due to respiration reaction. However, this calculation does not
311
take into consideration air humidity and, therefore, the calculated value of Msub remained the
312
same despite different water vapour pressure gradients under varying RH. Nevertheless, the
313
calculations were performed and compared to the TR of a single unpackaged strawberries at
314
different RH and temperatures (Fig. 1). The percentage contribution of substrate loss on TR at
315
RH lower than 96% was between 3 to 20%. This indicated that the water vapour pressure
316
gradient dominated the transpiration process. However, at saturated humidity (100%) as
317
normally observed in packaged fresh produce, the contribution of substrate loss on
318
transpiration rate of strawberry was very high (81 - 223%). It is established that the actual
319
transpiration rate or mass loss of fresh produce constitutes not only substrate loss but also
320
moisture loss due to heat of respiration which plays an important role in packaged produce
321
(Bovi, Caleb, Herppich, et al., 2018; Saltveit, 2004). Therefore, this approach to calculating
322
water loss based on substrate loss was not valid in the case of packaged fresh produce where
323
RH is very high. Calculation of transpiration rate of packaged fresh produce either based on
324
water vapour pressure gradient due to increase of surface temperature, heat of respiration,
325
substrate loss or carbon loss is still unresolved challenge and needs further attention.
326
Moreover, other mass flow components such as volatile organic compounds and ethylene,
327
also passing the fruit skin, are usually considered as negligible. Nevertheless, it may be that
328
they also play a role in total mass loss. In this context, the term total mass loss rate (TMLR)
329
will be used in this study, instead of TR, when referring to fresh produce packed in high
330
humidity environments as the mass loss due to substrate, and other mass flow components,
331
might be much more considerable in high humidities.
332
3.3.2. Packaged strawberries
333
For packaged strawberries a TMLR model based on the DOF was proposed. The DOF (%)
334
was calculated according to:
335
𝐷𝑂𝐹 = 𝑉𝑝𝑟𝑜𝑑𝑢𝑐𝑡
𝑉𝑝𝑎𝑐𝑘𝑎𝑔𝑒 x 100 (8)
336
where Vproduct is the product´s volume (ml) and Vpackage is the package´s volume (ml). For the
337
calculation of Vproduct strawberry density was considered to be 1 g ml-1.
338
The analyses of multiple packaged strawberries data showed that there was a negative linear
339
relationship between TMLR and DOF. Therefore, this data was used to develop a simple
340
TMLR model based on the DOF (Fig. 6). It is worth mentioning that this model was only
341
valid when the lidding film used is BOPP as the use of films with different water vapour
342
transmission rate would lead to different values of the TMLR. For instance, Bovi, Caleb, Ilte,
343
Rauh, and Mahajan (2018) reported that strawberries packaged with NatureFlex, Xtend, and
344
Polypropylene film lost 1.46, 0.41, and 0.27%, respectively, of the initial mass during storage
345
conditions at 5 °C for 14 d. These results showed another challenge of modelling mass loss of
346
packaged products as the permeability of the packaging material used is another important
347
factor to be considered. Moreover, further studies need to be carried out in order to evaluate
348
the effect of the number of micro-perforations on the TMLR of strawberries packaged in
349
BOPP film.
350
3.4. Experimental validation using packaged strawberries
351
In-package gas composition varied between 17 - 21% for O2 and 0 - 4% for CO2 during 5 d of
352
storage at 12 °C. After 2 d of storage, the in-package gas composition of all packages reached
353
equilibrium-modified atmosphere and it effectively maintained O2 and CO2 concentrations of
354
17 and 4%, respectively. Almenar, Catala, Hernandez-Muñoz, and Gavara (2009) reported O2
355
concentration of up to 14% for wild strawberries packed in containers covered with
356
polyethylene terephthalate/polypropylene multilayer films with three micro-perforations
357
stored at 10 °C for 4 d.
358
Furthermore, results showed that the micro-perforations led to saturated conditions within 1 h
359
of packaging. This observation can be compared with larger size chamber, 190 l (Fig. 3), with
360
a single strawberry where it reached the water vapor saturation after 10 h. This reinfornced
361
the hypothesis that lower headspace played a major role on TR as it was directly related to the
362
time needed for a system to reach water vapour saturation. The TR of packaged strawberries
363
was 0.03 ± 0.001 g kg-1h-1. The initial respiration rate of the packaged strawberries was 33.50
364
± 1.45 mgCO2 kg-1 h-1 and after 5 days of storage it was 54.12 ± 0.40 mgCO2 kg-1 h-1. Based
365
on the average respiration rate of day 0 and day 5 (43.81 mgCO2 kg-1 h-1), the substrate loss
366
for packaged strawberries was 0.03 g kg-1h-1. This indicates that the contribution of substrate
367
loss on actual measured TR was 100%. Therefore, once again this calculation seems not to be
368
realistic to calculate substrate loss due to respiration.
369
Moreover, the model based on DOF was used to predict mass loss of packaged strawberries
370
and was then compared with the experimental values (Fig. 7). The predicted mass loss of
371
strawberries packaged with BOPP film was only 446 mg which was much lower than
372
experimental value (717 mg). This experimental value of mass consisted of 20 mg
373
condensation in the tray, 47 mg condensation on the film, and 649 mg transmitted through the
374
micro-perforated packaging film. This analysis showed that it is possible to use water loss
375
predictive model, despite large error, to quantify the amount of moisture in the packaged fresh
376
produce. Such analysis can be used for selection of packaging materials and other active
377
moisture control strategies for controlling humidity and minimising condensation in packaged
378
strawberries. This modelling could eliminate the “pack and pray” approach normally adopted
379
for designing modified atmosphere and modified humidity packaging for respiring fresh
380
products.
381
4. Conclusion and future research needs
382
A key finding of this study is that headspace plays an important role in mass loss of packaged
383
strawberries and, therefore, the development of a model based on the DOF seems to be an
384
alternative to overcome the difficulties of developing water loss predictive models.
385
Furthermore, the findings of this study raised up some points that should be taken into
386
account for modelling of water loss, such as the deduction of substrate loss and consideration
387
of the degree of filling. Nevertheless, the question of how to quantify substrate loss in
388
packaged fresh produce still needs to be addressed.
389
Acknowledgement
390
This work was supported by Conselho Nacional de Desenvolvimento Científico e
391
Tecnológico (CNPq) through a PhD grant (201623/2015-3). The Georg Forster Postdoctoral
392
Research Fellowship (HERMES) programme from the Alexander von Humboldt Foundation
393
(Ref. ZAF–1160635–GFHERMES–P) is also appreciated.
394
List of Figures
395
396
Fig. 1 – Transpiration rate of single unpackaged strawberry and respiration rate of
397
strawberries under different storage conditions. The values on top of the bars represent the
398
percentage (%) of mass loss due to substrate usage or consumption.
399
8%
5%
3%
10%
7%
7%
14%
20%
16%
81%
223% 111% 0
20
40
60
80
100
120
140
160
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
20 °C 12 °C 4 °C
Respiration rate (mg CO2 kg-1 h-1)
Transpiration rate (g kg-1 h-1)
Temperature (°C)
76 %RH
86 %RH
96 %RH
100 %RH
RR
400
Fig. 2 – Experimentally determined transpiration rates (TR) of single unpackaged strawberry
401
versus water vapour pressure deficit (VPD).
402
403
Fig. 3 – Impact of relative humidity on surface temperature and associated mass loss of a
404
single strawberry.
405
406
y = 3,315x + 0,0057
R² = 0,9782
y = 3,0338x + 0,0675
R² = 0,9947
y = 2,0775x + 0,1737
R² = 0,9764
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
0,0 0,1 0,2 0,3 0,4 0,5 0,6
TR (g kg-1 h-1 )
VPD (kPa)
4°C
12°C
20°C
13,2
13,4
13,6
13,8
14,0
14,2
14,4
94
95
96
97
98
99
100
010 20 30 40 50 60 70 80
Temperature (°C)
Normalised mass / Humidity (%)
Storage time (h)
Strawberry mass Relative humidity Temperature, strawberry Temperature, air
407
408
Fig. 4 – Effect of (a) number of packaged strawberries on total mass loss and (b) container
409
volume on total mass loss of strawberries.The bars represent the total mass loss rate (g kg-1h-1)
410
whereas the dots represent the package headspace (l).
411
412
Fig. 5 – Description of changes in strawberry mass (g) for predicted versus experimental data,
413
and the model paramenters.
414
0,00
0,10
0,20
0,30
0,40
0,50
0,60
0,70
0,80
0,00
0,01
0,02
0,03
0,04
0,05
0,06
0,07
0,08
13615
Package headspace (l)
Total mass loss rate (g kg-1h-1)
Number of strawberries in a package
0,00
0,50
1,00
1,50
2,00
2,50
0,00
0,01
0,01
0,02
0,02
0,03
0,03
0,04
0,04
2,3 1,4 0,8
Package headspace (l)
Total mass loss rate (g kg-1h-1)
Package volume (l)
10
15
20
25
10 15 20 25
Mpredicted (g)
mexperimental (g)
(a)
(b)
415
Fig. 6 – Total mass loss rate of strawberry packaged in containers of different volumes and
416
proposed model based on percentage degree of filling (DOF).
417
418
Fig. 7 – Experimental distribution of total mass loss in packaged strawberries after 5 d at
419
storage and the predicted value of total mass loss at 24% dregree of filling (DOF) at 12 °C.
420
421
422
423
424
y = -0,0009x + 0,0398
R² = 0,7744
0
0,005
0,01
0,015
0,02
0,025
0,03
0,035
0,04
0 5 10 15 20 25 30
Total mass loss rate (g kg-1h-1)
DOF (%)
Experimental data
717
20 649 47
779
0 100 200 300 400 500 600 700 800
Experimental
Predicted
Total mass loss of packaged strawberry, mg
Mass loss of strawberries Condensed water: Tray
Transmitted water Condensed water: Film
446 (DOF:24 %)
References
425
Almenar, E., Catala, R., Hernandez-Muñoz, P., & Gavara, R. (2009). Optimization of an
426
active package for wild strawberries based on the release of 2-nonanone. LWT - Food
427
Science and Technology, 42(2), 587-593. doi:
428
http://dx.doi.org/10.1016/j.lwt.2008.09.009
429
Bovi, G. G., Caleb, O. J., Herppich, W. B., & Mahajan, P. V. (2018). Mechanisms and
430
Modeling of Water Loss in Horticultural Products Reference Module in Food Science:
431
Elsevier.
432
Bovi, G. G., Caleb, O. J., Ilte, K., Rauh, C., & Mahajan, P. V. (2018). Impact of modified
433
atmosphere and humidity packaging on the quality, off-odour development and
434
volatiles of ‘Elsanta’ strawberries. Food Packaging and Shelf Life, 16, 204-210. doi:
435
https://doi.org/10.1016/j.fpsl.2018.04.002
436
Bovi, G. G., Caleb, O. J., Klaus, E., Tintchev, F., Rauh, C., & Mahajan, P. V. (2018).
437
Moisture absorption kinetics of FruitPad for packaging of fresh strawberry. Journal of
438
Food Engineering, 223, 248-254. doi: https://doi.org/10.1016/j.jfoodeng.2017.10.012
439
Bovi, G. G., Caleb, O. J., Linke, M., Rauh, C., & Mahajan, P. V. (2016). Transpiration and
440
moisture evolution in packaged fresh horticultural produce and the role of integrated
441
mathematical models: A review. Biosystems Engineering, 150, 24-39. doi:
442
http://dx.doi.org/10.1016/j.biosystemseng.2016.07.013
443
Bovi, G. G., & Mahajan, P. V. (2017). Regulation of Humidity in Fresh Produce Packaging
444
Reference Module in Food Science (pp. 1-6): Elsevier.
445
Caleb, O. J., Mahajan, P. V., Al-Said, F. A., & Opara, U. L. (2013a). Modified Atmosphere
446
Packaging Technology of Fresh and Fresh-cut Produce and the Microbial
447
Consequences—A Review. Food and Bioprocess Technology, 6(2), 303-329.
448
Caleb, O. J., Mahajan, P. V., Al-Said, F. A., & Opara, U. L. (2013b). Transpiration rate and
449
quality of pomegranate arils as affected by storage conditions. CyTA - Journal of
450
Food, 11(3), 199-207.
451
Chau, K. V., & Gaffney, J. J. (1990). A Finite-Difference Model for Heat and Mass Transfer
452
in Products with Internal Heat Generation and Transpiration. Journal of Food Science,
453
55(2), 484-487. doi: 10.1111/j.1365-2621.1990.tb06792.x
454
Kang, J. S., & Lee, D. S. (1998). A kinetic model for transpiration of fresh produce in a
455
controlled atmosphere. Journal of Food Engineering, 35(1), 65-73.
456
Kays, S. J. (1991). Postharvest physiology of perishable plant products: Van Nostrand
457
Reinhold.
458
Linke, M., Schlüter, O., & Geyer, M. (2008). A simple atmospheric evaporation device as a
459
useful tool for validation of air flow models and for process control applications.
460
Paper presented at the IV International Symposium on Applications of Modelling as
461
an Innovative Technology in the Agri-Food-Chain: Model-IT, Acta Horticulturae
462
(ISHS), Madrid, Spain.
463
Mahajan, P. V., Oliveira, F. A. R., & Macedo, I. (2008). Effect of temperature and humidity
464
on the transpiration rate of the whole mushrooms. Journal of Food Engineering, 84(2),
465
281-288.
466
Mahajan, P. V., Rux, G., Caleb, O. J., Linke, M., Herppich, W., & Geyer, M. (2016).
467
Mathematical model for transpiration rate at 100% humidity for designing modified
468
humidity packaging. Paper presented at the III International Conference on Fresh-cut
469
Produce. Acta Horticulturae (ISHS), University of California, Davis.
470
Matyssek, R., & Herppich, W. B. (2017). Experimentelle Pflanzenökologie: Physik des
471
Wasserdampfes – Luftfeuchte und Wasserdampfgradienten Experimentelle
472
Pflanzenökologie. Spektrum, Berlin, Heidelberg: Springer Reference
473
Naturwissenschaften.
474
Rodov, V., Ben-Yehoshua, S., Aharoni, N., & Cohen, S. (2010). Modified Humidity
475
Packaging of Fresh Produce Horticultural Reviews, Volume 37 (pp. 281-329): John
476
Wiley & Sons, Inc.
477
Rux, G., Caleb, O. J., Geyer, M., & Mahajan, P. V. (2017). Impact of water rinsing and
478
perforation-mediated MAP on the quality and off-odour development for rucola. Food
479
Packaging and Shelf Life, 11, 21-30. doi: http://dx.doi.org/10.1016/j.fpsl.2016.11.003
480
Saltveit, M. E. (2004). Respiratory metabolism. The commercial storage of fruits, vegetables,
481
and florist and nursery stocks, 68.
482
Sastry, S. K. (1985). Moisture losses from perishable commodities: recent research and
483
developments. International Journal of Refrigeration, 8(6), 343-346.
484
Sastry, S. K., & Buffington, D. E. (1983). Transpiration rates of stored perishable
485
commodities: a mathematical model and experiments on tomatoes. International
486
Journal of Refrigeration, 6(2), 84-96.
487
Shirazi, A., & Cameron, A. C. (1993). Measuring transpiration rates of tomato and other
488
detached fruit. HortScience : a journal of the American Society for Horticultural
489
Science, 28(10), 1035-1038.
490
Sousa-Gallagher, M. J., Mahajan, P. V., & Mezdad, T. (2013). Engineering packaging design
491
accounting for transpiration rate: Model development and validation with strawberries.
492
Journal of Food Engineering, 119(2), 370-376.
493
Xanthopoulos, G. T., Athanasiou, A. A., Lentzou, D. I., Boudouvis, A. G., & Lambrinos, G.
494
P. (2014). Modelling of transpiration rate of grape tomatoes. Semi-empirical and
495
analytical approach. Biosystems Engineering, 124, 16-23.
496
Xanthopoulos, G. T., Templalexis, C. G., Aleiferis, N. P., & Lentzou, D. I. (2017). The
497
contribution of transpiration and respiration in water loss of perishable agricultural
498
products: The case of pears. Biosystems Engineering, 158, 76-85. doi:
499
http://dx.doi.org/10.1016/j.biosystemseng.2017.03.011
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
